Interact Pro gateway

The heart of the connected lighting system

Interact Pro gateway is the heart of the connected lighting system. It connects the system to the cloud via the Internet. It enables the Interact Ready luminaires, lamps and accessories to communicate sending information to the cloud and the system to be accessed via the Interact Pro apps and dashboard. The gateway features an easy commissioning process during the initial installation.

The Interact Pro gateway establishes secure wireless Zigbee connections with up to 200 light points. The wireless connection allows bi-directional control and sensor data to be exchanged between Interact Ready luminaires, lamps, sensors and switches and the Interact Pro system and software.

Benefits and features

Clean, intuitive design

The gateway features a compact, attractive design with a mounting bracket in white to suite any business environment. 3 LED indicators give feedback on power, internet connectivity and communication to the Interact cloud.

Secure and encrypted

The wireless gateway delivers secure and encrypted wireless network communication. Third party Zigbee devices can only join the network if their unique identifiers are explicitly enabled within the Interact Pro system by the administrator.

Robust, peer-to-peer connectivity

The Zigbee protocol enables a fully distributed, peer-to-peer communications model whereby the application is divided over all the devices in the network. The result is that if one device in the network is not functioning (is removed or defective), the remaining devices keep functioning as intended.

Remote management

The gateway can be remotely managed, upgraded and controlled via the mobile Interact Pro app or web-based dashboard over the Internet. Functions of the wireless gateway and all connected devices can be modified with software configurable settings.

Scaleable and future-ready

The Interact Pro gateway establishes a secure wireless connection with up to 200 Interact Ready luminaires or lamps. In addition, 15 sensors and 15 switches can also be connected.

Specification

Name	Value
Mounting bracket dimensions (length, width, height)	97 x 97 x 34 mm (3.8 x 3.8 x 1.3 in)
Gateway housing dimensions (length, width, height)	91 x 91 x 26 mm (3.6 x 3.6 x 1 in)
Gateway housing weight (incl. mounting bracket)	95g (0.21lb)
Power consumption	Max. 2.8 w
Communication ports	2 x 10/100 BaseT ports ZigBee port
Supported ethernet protocols	IPv4, TCP, UDP
Ethernet	RJ45
Wireless communication	ZigBee PRO standard (EEE 802.15.4 WPAN)

Interact Ready products

Interact Ready luminaires from Philips

Interact Ready lamps from Philips

Zigbee GreenPower switches from Philips

Interact Ready sensors from Philips

View Philips Interact Ready products (Philips Lighting website)

Want to know more?

For more information download the Interact Pro gateway specification sheet.
